Network Video Recorder
Specification
| Type | NVR |
| Order No. | NVR002 |
| Material | Metal |
| Decoding Format | Ultra 265,H.265,H.264 |
| Temp.range min | -10℃ |
| Temp.range max | +55℃ |
| Vibration(0-100Hz) | 0.7g |
| IP Video input | 32-ch |
| Operational Areas | Indoor |
| Mounting | In KDRACK system |
| Bandwidth | 384Mbps |
| Recording Resolutions | 32MP/16MP12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/2CIF/CIF |
| Corridor Mode Screen | 3/4/5/7/9/10/12/16/32 |
| Decoding Capability | 2×32 MP@30,4x16MP@30,5×12 MP@30,8x 4K@25,16×4MP@30,32x1080P@30 |
| Hard Disk SATA | 8 SATA interfaces |
| Capacity | up to 16TB for each HDD |
| General Alarm | Defocus Detection,Scene Change Detection,Object Left Behind,Object Removed,Auto Tracking,Motion Detection,Tampering,Video Loss Alarm Input,Audio Detection |
| Voltage | 100~240 VAC Power Consumption:≤50W(without HDD) |
| Net Weight | ≤6kg |
Dimension
